CHIPAX TECHNOLOGY CO., LTD.
Specifications
- LCD Monitor
- Screen Size: 19.1"
- Brightness: 350 cd/m2
- Display Color: 16,777,216 color
- Lamp Life Time: 50,000 hours (min)
- Ultra-wide Viewing Angles: 170 degrees, all directions
- High Resolution SXGA-wide resolution: 1280 x 1024 pixels
- Response Time: 15ms
- Display Dot Area: 376.32mm x 301.056mm
- TV Tuner
- Support TV System: NTSC / PAL.
- Auto-scan tuning of broadcast and TV channels.
- On-Screen Display (OSD) menu controls for picture and other setting adjustments.
- Support both TV and CATV (Cable TV) 181 full channels.
- VOV (Video-On-Video) display function.
- MTS function.
- PC Monitor
- Resolution: 1280 x 1024 pixels
- 15 pin D-Sub DVI-D connector.
- AV
- Built-in audio amplifier (6W x 2)
- Stereo Audio.
- Speaker x 2
- Earphone Connector.
- General
- Power System: DC Input 10 ~ 16V
- Operating Voltage Range: DC 13V/6.2A
- Operating Temperature Range: 0°C ~ 50°C
- Maximum Relative Humidity: 85%
- Weight (Net): 8.5 kgs
- V-Chip.
- 3D Comb Filter.
- AC Adapter: AC Input 110 ~ 240V
- Power Consumption: 70W
- Storage Temperature Range: -20°C ~ 60°C
- Dimensions (Unit): TBD
- Regulatory Certifications: FCC
- Closed Captioning.
- Front Control
- Power on/off.
- Volume up.
- Channel up.
- Menu/Enter.
- Audio/Video source select.
- Volume down.
- Channel down.
- Rear Recessed I/O
- Composite Video Input Connector x 1
- S-Video Input Connector x 1
- SHeadphone Jack x 1
- SPower Input x 1
- Component Video Input Connector x 1
- DB-15 VGA Input Connector x 1
- STV Antenna Input Connector x 1
- Cabinet
- Unique cabinet design.
- Panel
- Fujitsu FLC48SXC8V-10
- Specifications are subject to change without notice.
Features
- Full-functioned TV set.
- CATV full-frequency channel reception.
- Great computer display.
- Multiple terminal functions for digital graphic.
- Device and other home entertainment device.
- Fashionable design as a decoration.
- Lightweight.
- Slim design to fit in any place.
- Super brightness.
- High resolution, A++ grade 19" TFT-LCD Panel.
- Super wide view angle.
- Super low power consumption.
Main Products
LCD Monitor, LCD TV, POP, IN-Car Accessories
