| Fo (MHz) | Mode | RS (ohm) Max |
|---|---|---|
| 3.579545 | Fund | 150 |
| 4.000 | Fund | 150 |
| 4.43319 | Fund | 150 |
| 6.000 | Fund | 100 |
| 7.3728 | Fund | 80 |
| 8.000 | Fund | 80 |
| 10.245 | Fund | 60 |
| 11.0592 | Fund | 50 |
| 12.000 | Fund | 50 |
| 14.31818 | Fund | 40 |
| 16.9344 | Fund | 40 |
| 17.734475 | Fund | 40 |
| 18.432 | Fund | 40 |
| 20.000 | Fund | 40 |
| 22.1184 | Fund | 40 |
| 24.576 | Fund | 40 |
| 33.8688 | Fund | 40 |
| 36.864 | 3rd | 80 |
| 40.000 | 3rd | 80 |
| 48.000 | 3rd | 80 |
| 60.000 | 3rd | 80 |
Specifications
- Frequency range: 3.200 - 60.000 MHz
- Frequency tolerance: ± 30 ppm at 25°C
- Temperature stability: ± 50 ppm over -10°C ~ 70°C
- Drive level: 1mW Max
- Load capacitance: 12 - 32 pf, series
- Shunt capacitance: 7 pf Max
- Equipment series resistance: see below
Certificate
- ISO 9002
