Guger Industries Co., Ltd.
Specifications
- Roller Core Dimension : φ20 x φ60 x 100 (mm)
- Stroke : 350 (mm)
- Work Table : 280 x 380 (mm)
- Max. Opening : 300 (mm)
- Reach : 210 (mm)
- Heater Capacity : 400 x 6
- Dimension (L x W x H) : 1,340 x 700 x 1,800 (mm)
- Packaging WT. : 320 kg
- Packaging Dimension : 850 x 1,400 x 1,900 (mm)
- Net WT : 250 kg
Features
- To control sequence with three timers: Press, Deley, Foil Feed. The adjustment is easily as one's pleases and accuracy.
- Operating temperature can be adjusted from 0 ~ 400°C easily and accurately.
- Double foil feed roll guide.
- High efficiency structure of pneumatic system and an auto lubricator is employed with easily adjustment and high stability and durability.
- Beam sensor is easy to adjust and accuracy.
- The level of herater is easily and fast adjusted.
- Accuracy depth adjustment can be achieved with micro-adjustment.
- FC25 structure is steel casting never deformed and good lasting.
- Foil feeder with special motor rotates very accurately.
- Aluminum alloy plate is light and strong.
- Both hands push button prevent industrial accident.
- The machine can be easily moved by the working table with wheels.
- Foot switch with safety cover.
