The parameter of the HPD008B type has two models, F7012 and F7024. Two of the types share the same input votage in AC90~264V, input frequency 47~63Hz and same operating temperature, around -20~50℃. As for the output voltage, the F7012 ranges from 4~12V while the F7024 ranges from 16~24V. This type of thecurrent driver share the same output current range, 700mA.
The dimension of the two models are the same, 103mm(L)*50mm(W)*30mm(H). So, you should pay attention to the output voltage or current range. In this way, you can find your own constant current driver efficiently. Moreover, our products are certified with CE/FCC. If you are interested in our products, please feel free and contact us today!
The dimension of the two models are the same, 103mm(L)*50mm(W)*30mm(H). So, you should pay attention to the output voltage or current range. In this way, you can find your own constant current driver efficiently. Moreover, our products are certified with CE/FCC. If you are interested in our products, please feel free and contact us today!
| Parameter | HPD008B-F7012 | HPD008B-F7024 |
|---|---|---|
| Input Voltage | AC90~264V | |
| Input Frequency | 47~63Hz | |
| Output Voltage Range | 4~12V | 16~24V |
| Output Current Range | 700mA | 700mA |
| Max. Output Power | 8.4W | 16.8W |
| 3W White LED in Series(Min.~Max.) | 2~3pcs | 5~6pcs |
| Operating Temperature | -20℃~50℃ | -20℃~50℃ |
| Dimension | 103mm(L)*50mm(W)*30mm(H) | |
| Certified | CE / FCC |
